$ 95.21
This system is a 2-user, galvanized steel vertical safety system (vertical lifeline) that meets the new ANSI Z359.16 standard, along with OSHA 1910.140 and 1926.502, when used with the Lad-Saf X3 Detachable Cable Sleeve (6160054) and Lad-Saf X2 Detachable Cable Sleeve (6160030). It includes the top and bottom brackets, 60’ of swaged 3/8 inch 1×7 galvanized steel cable, and 2 guides.
This complete system includes all brackets, pre-swaged cable, and cable guides, all in a single SKU. This system is a 2-user, galvanized steel vertical safety system (vertical lifeline) that meets the new ANSI Z359.16 standard, along with OSHA 1910.140 and 1926.502, when used with the Lad-Saf X3 Detachable Cable Sleeve (6160054) and Lad-Saf X2 Detachable Cable Sleeve (6160030). It includes the top and bottom brackets, 60’ of swaged 3/8 inch 1×7 galvanized steel cable, and 2 guides. The system has been reengineered to simplify and speed up the installation process, weighing less and with fewer loose parts than our previous models. Additionally, the top bracket provides 100% tie-off capability through its integrated fall arrest-rated anchor point rated to 3,600 lbs. This version is ideal for billboards and ladders, with mounting brackets that can be used on a variety of fixed ladder styles that may consist of different rung spacings and shapes. See our Technical Data Sheet (“TDS”) for more information, including operating temperature ranges, compatible rung spacings and shapes, weights and dimensions, etc.
Our 3M™ Protecta® Rebel™ Web Self-Retracting Lifelines are housed in durable, super-tough composite and provide an economical fall protection solution without compromising on performance or safety.
An SRL’s lifeline will extend as the user moves away, and retract automatically enabling the user to move about within a recommended working area at normal speeds. Should a fall occur, a speed sensing brake system will activate stopping the fall and reducing the forces imposed on the user to safe levels.
The Rebel Web can be connected from shoulder level and has a 140 kg (310lbs) weight capacity. The top swivel anchorage connector limits lifeline twisting and improves user experience. The super tough nylon housing is lightweight, compact, durable and UV resistant. The built in impact indicator allows for visual inspection and the heat shrunk clear PVC coating on the shock pack provides an easy to read label.
Certified to CE standard EN360.
What’s in the box:
– 3M 3100437 SRL
– Carabiner x1
– Usage Manual
130 ft. (39m) of 3/16″ (5mm) stainless steel wire rope with swivel snap hook, anchorage carabiner, 4 ft. (1.2m) cable tie-off adaptor.
These Sealed-Blok™ self retracting lifelines (SRL’s) incorporate a patented concept that separates all dynamic components, including the motor spring and brake, from foreign elements such as grease, moisture and dirt. You can always trust your SRL to work at peak efficiency without worrying about the environment you’re working in. Our sealed SRLs are backed by decades of proven field service for absolute confidence, safety and reliability. An SRL’s lifeline will extend as the user moves away, and retract automatically enabling the user to move about within a recommended working area at normal speeds. Should a fall occur, a speed sensing brake system will activate stopping the fall and reducing the forces imposed on the user to safe levels.
Single fall arrest dorsal D-ring D-ring: White galvanized steel Adjustable thigh & chest straps Cushion back pad to enhance comfort 44mm dual color polyester web strap Buckles: White galvanized steel Net weight: 810g Norm: EN361:2002
Portable anchors used in a variety of applications. Many are ‘choker’ style, designed to provide a safe and easy way to anchor a fall protection device to an overhead location that is beyond normal reach
Thimble ends:Corrosion resistant
PVC protective sleeve:Wears less than conventional sling
galvanised steel:light in weight
5-points adjustment full body harness with dorsal D-ring and extremely cost-effective fall arrest harness for general safety.
Polyester webbing has good performance in abrasion and heat resistance. Ensure your safety with this safe and secure full body harness. Suitable for construction, window washer, gutter cleaning, roofing work and more.
Features:
6 ft. (1.8m) twin-leg lifelines with 3/4″ (19mm) Dyneema® fiber and polyester web and steel rebar hooks, quick connector for harness mounting.
Nano Lok™ is ergonomically designed for ease of use and is ideal for direct connection to most harnesses. The extremely compact and lightweight design is virtually unnoticeable on your back, staying out of the worker’s way and making it ideal as a lanyard replacement. Whether your application requires single or twin leg configurations, mounting to an overhead anchor or for connection directly to harness, there are more than 30 models to choose from to suit almost any application. Nano Lok™ locks quickly—stopping a fall within inches—providing more protection at low heights. In addition, tension is always kept on the lifeline, which reduces dragging, snapping and trip falls. Both features are key safety improvements.
| ART. NO. | A-050 |
|---|---|
| EAN | 4030281286943 |
| STANDARD | DIN EN 12841-C:2006, DIN EN 15151-1:2012, DIN EN 341-2A:2026 |
| ABSEILING SPEED | 2,00 m/s |
| E-CLASS NUMBER | 40-02-01-06 |
| MAX. SERVICE LIFE | 30 Years |
| RATED LOAD | 250 KG |
| TEMPERATURE | 60 °C – -30 °C |
| CUSTOMS NO. | 84798997 |
| SIZE | 47x79x175mm |
| WEIGHT | 0,51 kg |
| MATERIAL | Aluminium, Steel |
Miller 21049 allows for exiting and entering the GlideLoc fall arrest system using fall arresters. Stainless steel construction.
Miller GlideLoc Ladder Systems give you an innovative solution to vertical climbing which is easy to use, requires a minimum of maintenance & provides unsurpassed safety. The GlideLoc System provides hands free safety at height which increases worker safety, productivity and mobility.
Fall arrester sliding on anchorage line stranded rope Ø 14 mm (rope sold separately). Opening type fall
arrester equipped with automatic locking, non-inverting device, energy absorber with fall indicator. 1
carabiner AM002.
Stainless steel.
COLOUR
Steel
SIZE
No size
